What Is A Spray Granulation Dryer

2022 06/21

The spray granulation dryer is a kind of drying equipment that produces products after reaching the particle size requirements by fluidizing, dedusting, atomizing, and curing the materials. The technical process is generally that the air enters the bottom of the fluidized bed after being heated by the heater, and passes through the distribution plate to contact the material to make the material fluidized. The mother liquor or binder is respectively sent to the atomizing nozzle by the pressure pump and other pressure-making equipment. After atomization, it is coated on the surface of the fluidized particles or the particles are bonded to each other. After continuous fluidization, coating and drying, the particles gradually grow. When the required particle size is reached, it will be discharged from the discharge port of the fluidized bed. Widely used in chemical, pharmaceutical, food and other industries.

Main feature:

1. The drying speed is fast, and the surface area of the material liquid is greatly increased after atomization. In the hot air flow, 95-98% of the water can be evaporated instantly, and the drying time is only ten to ten seconds. It is especially suitable for For drying of heat-sensitive materials;

2. The obtained products are spherical particles with uniform particle size, good fluidity, good solubility, high product purity and good quality;

3. It can be used in a wide range. According to the characteristics of the material, it can be dried with hot air or granulated with cold air, which has strong adaptability to materials;

4. The operation is simple and stable, the control is convenient, and it is easy to realize automatic operation.

The technological process of spray granulation dryer:

1. The pressure spray granulation dryer is mainly composed of a feeding system, a drying system, a dust removal system, a heating system and an electrical system, and each system includes some related equipment;

2. The feeding system consists of a mixing tank, a filter, a diaphragm pump and a spray gun. The ball-milled secondary slurry is transferred from the ball mill to the mixing tank, extracted and transported by the diaphragm pump through the filter, and then enters the drying tower through the spray gun;

3. The slurry enters the drying tower from the spray gun nozzle to start the spray granulation drying process.

The above is about rubber machinery. If you want to know more about our company's dynamics or products, you can consult us. We also sell Dispersion Kneader, Rubber Internal Mixer, Rubber Open Mill, Two Roll Mill, Plastic Granulator and Extrusion Pelletizer.
